04Aug 2017 by kelipacking

QP-PY02 Pyramid tea packing machine

The packaging bags with thread .all the works Of bagmaking ,measuring filling ,sealing ,cutting Can be done automatically.It is suitable for automatically packaging of steeping products such as framgental tea ,medicinal tea,coffee etc. QP-PY02 Pyramid tea packing machine Applications:: Be used for automatically packing products as green tea ,black tea, flower tea ,health tea, medicine tea, granule and so on . Functions: 1.This unit can perform either three sides sealing or triangle teabag .just need single bond to change the bag between three sides sealing and triangle shape. 2. Packaging capacity: 3000bags/h (Determined by packing material) 3. Applicable packing materials: Nylon film with thread and label. 4. The precision volumetric metering way very easily in the transformation of filling material. Electronic scale metering can be collocated according to the…

04Aug 2017 by kelipacking

QP-CR Inline capsule machine

Tea Coffee Packing Machine

Servo screw filling, filling accuracy about 1.5%,you can adjust filling quantity by setting parameters in touch screen . No cup, no filling; the machine will stop and alarm automatically while screw getting stuck. Automatic detection of coffee hopper : vacuum feeder will open automatically if coffee is less. One click clear : clear the remaining coffee in the hopper. Coffee store cylinder with nitrogen filled joint to fill nitrogen. QP-CR Inline capsule machine Feature: 1.Automatically complete packaging process,small occupation space,and easy to operate. 2.PLC control system,full display and real-time monitoring. 3.Automatically load lid and capsule,heat seal,cups out put. 4.Vacuum feeding coffee powder or Screw feeding powder, it is optional. 5.Servo motor control auger filling powder,high filling accuracy ,±0.1g. 6.Liquid injection(flavor and other), optional function. 7.Press powder and clean cup…

04Aug 2017 by kelipacking

QP-CI Rotary Capsule Machine

Tea Coffee Packing Machine

Automatically complete packaging process,small occupation space,and easy to operate,PLC control system,full display and real-time monitoring,Automatically load lid and capsule,heat seal,cups out put,Vacuum feeding coffee powder or Screw feeding powder, it is optional. QP-CI Rotary Capsule Machine Feature: 1.Automatically complete packaging process,small occupation space,and easy to operate. 2.PLC control system,full display and real-time monitoring. 3.Automatically load lid and capsule,heat seal,cups out put. 4.Vacuum feeding coffee powder or Screw feeding powder, it is optional. 5.Servo motor control auger filling powder,high filling accuracy ,±0.1g. 6.Liquid injection(flavor and other), optional function. 7.Press powder and clean cup margin dust and remainder powder. 8.Nitrogen protection system,filling nitrogen line from capsule loading to heat seal,besides hopper has nitrogen input.95%-98% nitrogen content in the cup. 9.No cups,no filling. 10.Automatically detect lids quantity,less than setting parameters,alarm and arise…

04Aug 2017 by kelipacking

QP-CA Semi auto capsule machine

Tea Coffee Packing Machine

output: 300-400 cups/hour heat power: 0.5 Kw air consumption: 0.4 m3/min voltage: ~220V 50Hz machine dimension: 800mm*600mm*500mm weight: about 80kg QP-CA Semi auto capsule machine rotary type filling & sealing machine Technical date: output: 300-400 cups/hour heat power: 0.5 Kw air consumption: 0.4 m3/min voltage: ~220V 50Hz machine dimension: 800mm*600mm*500mm weight: about 80kg Function: put cup by hand automatic put foil turn rotary table by hand automatic sealing take cup out by hand

04Aug 2017 by kelipacking

QP-190 Drip filter bag packing machine

Tea Coffee Packing Machine

Adopt the special drip filter bag with three sides sealing,which can be directly hung against the cup edge to have a better brewing effect;moreover,the neat bag shape is high fashion in the overseas markets. QP-190 Drip filter bag packing machine Appliciations: The machine is suitable for the powdered coffee and other small particles of material. Features: 1.Adopt the special drip filter bag with three sides sealing,which can be directly hung against the cup edge to have a better brewing effect;moreover,the neat bag shape is high fashion in the overseas markets. 2.All the works of bag making,measuring,filling,sealing,cutting,counting,batch number printing and other functions can be done automatically. 3.The machine is controlled by a precise control system and provided with an Man-Machine interface(MMI),compact structure,convenient operation and adjustment and easy to maintemance. 4.The…

04Aug 2017 by kelipacking

QP-180 Inner bag outer bag tea packing machine with thread and tag

Tea Coffee Packing Machine

The packaging bags with thread .all the works Of bagmaking ,measuring filling ,sealing ,cutting Can be done automatically.It is suitable for automatically packaging of steeping products such as framgental tea ,medicinal tea,coffee etc. QP-180 Automatic tea-bag inner and outer bag packing machine APPLICATIONS： The machine is suitable for the dual bag packing of small grain-like materials, such as tea leafs, medicinal tea and healthy teas. FEATURES： AUTOMATIC TEA-BAG PACKING MACHINE WITH THREAD，TAG AND ENVELOPE is a hot-sealed, automatic and multifunction packing equipment ,The main characteristic of this equipment is it can molding in one time to protect the material from the direct contact with workers’ hands and improve the efficiency. The inner bag is filter paper with thread and label automatically is available. The outer bag is composite paper…

04Aug 2017 by kelipacking

QP-170 filter tea packing machine with thread and tag

Tea Coffee Packing Machine, Triangle Tea Bag Packing Machine with Thread And Tag

It is suitable for packing of broken tea, coffee, ginseng essence, diet tea, health-caring tea, medicine tea, as well as tea leaves and herb beverage.The machine can automatically finish bag making, measuring, filling, sealing, thread feeding, tag cutting and counting, QP-170 filter tea packing machine with thread and tag APPLICATIONS It is suitable for packing of broken tea, coffee, ginseng essence, diet tea, health-caring tea, medicine tea, as well as tea leaves and herb beverage. FEATURES The machine can automatically finish bag making, measuring, filling, sealing, thread feeding, tag cutting and counting, PACKING MATERIAL: TEA PAPER, THREAD, TAG TECHNICAL DATA Filling Range: about 1.5-5g of broken tea Bag Size: 60-75mmx55-70mm Tag Size: W: 28×L:23-28mm Packing Speed: 30-60bag/min Dimensions: 900×950×1800 mm Weight: 400KG Total Power: 220V/50HZ/1.6KW

04Aug 2017 by kelipacking

QP-160 Filter paper tea packing machine with thread

Tea Coffee Packing Machine

The packaging bags with thread .all the works Of bagmaking ,measuring filling ,sealing ,cutting Can be done automatically.It is suitable for automatically packaging of steeping products such as framgental tea ,medicinal tea,coffee etc. QP-160 Tea-Bag Automatic Packaging Machine APPLICATIONS：It is suitable for automatically packaging of steeping products such as framgental tea ,medicinal tea,coffee etc. FEATURES：The packaging bags with thread .all the works Of bagmaking ,measuring filling ,sealing ,cutting Can be done automatically. PACKING MATERIALS：TEA PAPER 、THREAD TECHNICAL DATA： BAG SIZE L：40-100（mm） W：45-75（mm） CAPACITY 40-60（bag/min） FILLING RANGE 3-15（ml） TOTAL POWER AC 220V/50HZ/1.6KW WEIGHT 350Kg DIMENSION （L*W*H） 640×1100×1850 (mm)
